Question

free-body diagrams ... the sequel with task tracker
a puck moves to the right over a cushion of air at a constant speed on an air hockey table. the puck is not contacting the table.
identify the type of forces and their relative magnitude.
tap a direction and id the force type. tap an arrow on the diagram to change the size of the force. tap check answer when ready.
select a direction:
right left up down
id the rightward force.
none gravity normal friction
applied air resist. spring tension
check answer

student aids
interactives
usage policy
about
physics interactives pack
concept checkers
kirby simulations
1d kinematics (12)
newtons laws (8)
vectors and projectiles (14)
forces in 2d (5)
momentum, collisions and explosions (8)
work and energy (6)
visit: free-body diagrams...the sequel teacher notes

Explanation:

Step1: Analyze motion conditions

The puck moves right at constant speed, so net force is 0 (Newton's 1st Law).

Step2: Identify vertical forces

Gravity acts downward, Normal force acts upward; they balance.

Step3: Identify horizontal forces

Air hockey cushion means no contact friction. No applied force is acting, so no rightward/leftward forces.

Step4: Match to options

Rightward force: None. Vertical forces: Gravity (down), Normal (up), balanced. No horizontal contact/applied forces.

Answer:

For the rightward force selection: None
Vertical forces: Gravity (direction: Down), Normal (direction: Up, equal magnitude to Gravity)
Horizontal forces: No other forces (Applied, Friction, etc.) act on the puck.
